Automatic Chamber Diaphragm Filter Press

Name: Automatic Chamber Diaphragm Filter Press
SKU: 15958
Availability: InStock

$7,800.00

A robust, high-efficiency solid-liquid separation solution for chemicals, mining, environmental protection, and food processing industries. Its core structure uses recessed filter plates to form enclosed chambers, removing the need for separate filter frames and simplifying operation.

Slurry pumped into the chambers undergoes pressure-driven filtration: liquid passes through filter media, and solid particles are trapped to form uniform filter cakes. Boasting superior sealing, stable performance, and easy cake discharge, it excels at handling high-viscosity slurries. This cost-effective, low-maintenance equipment is your ideal choice for material purification, wastewater treatment, and residue recovery.

Add to compare

Add to wishlist

Size and packaging guidelines

Fermentum scelerisque hendrerit parturient nullam enim lobortis litora parturient dictumst.

Potenti a quisque tincidunt venenatis adipiscing parturient fermentum nisl tincidunt amentu.

Scelerisque conubia lobortis a condimentum ad eleifend dui integer maecenas habitant nostra.

Specification	Chair	Armchair	Sofas
Height	37"	42"	42"
Width	26.5"	32.5"	142"
Depth	19.5"	22.5"	24.5"
Assembly Required	No	No	Yes
Packaging Type	Box	Box	Box
Package Weight	55 lbs.	64 lbs.	180 lbs.
Packaging Dimensions	27" x 26" x 39"	45" x 35" x 24"	46" x 142" x 25"

分类： Filter Press, Recessed Chamber Filter Press

描述

Automatic Chamber Diaphragm Filter Press

This filter press is designed for separating solids from liquids in various slurry applications. It features a series of filter plates arranged to form chambers. Driven by a hydraulic pump, the slurry is forced into these chambers where the filtration media (filter cloth) separates the solid and liquid phases.

A chamber filter press is a type of filter press widely used across various industries for solid-liquid separation. It is commonly employed in wastewater treatment plants, mining operations, the chemical industry, and food processing facilities.

It forces the liquid portion to pass through filter cloth while retaining solid particles within the chambers. The basic structure of a chamber filter press consists of a series of filter plates with filter cloth, alternating with solid plates. The filter plates in our products are typically made of materials such as polypropylene, cast iron, or stainless steel, depending on the application and the nature of the material being filtered. Each plate features a central cavity or chamber where solids accumulate during the filtration process.

Filtration Principle: The filter cloth acts as a medium, allowing liquid to pass through while retaining solids. This results in the formation of a filter cake within the chambers and the collection of filtrate, thereby achieving efficient solid-liquid separation.

Advantages of Chamber Filter Press

1.High Filtration Efficiency: We utilize advanced filtration technologies, such as precise filter cloth arrangement and optimized plate design, to achieve highly efficient filtration performance.

2.Robust and Durable Construction: The filter plates are typically made from high-strength polypropylene or other corrosion-resistant materials.

3.Excellent Sealing Performance: The chamber filter press is equipped with a reliable sealing system that prevents leakage and ensures consistent pressure is applied throughout the filtration process.

4.User-Friendly Operation: The equipment features automated or semi-automated control systems that simplify operation and reduce manual intervention.

5.Wide Range of Applications: Customization options are available to tailor the filter press to meet specific process requirements.

其他信息

Specification	300-2000mm
Pressure	Mechanical Pressure
Motor Power	15-26kw
Feature	Membrane Expression
Application	Sand and Gravel Factory/Juice Industry
