MGK CNC cylindrical grinding machine
$50,000.00a set of
Automatic Sludge Dewatering Filter Press
$9,800.00
Our chamber filter press stands out as a core equipment for precise solid-liquid separation, widely applied in chemical, environmental, mining, food, and new energy industries worldwide. Adopting advanced hydraulic technology with 22MPa maximum pressure, it reduces cake moisture to 15-35% and cuts energy consumption by 40% .
Featuring reinforced polypropylene or stainless steel filter plates, it resists pH 1-14 corrosive media and works stably at -20℃ to 120℃. The PLC automatic control system enables unmanned operation, shortening cycles to 0.5-2 hours .
With 99%+ solid recovery rate and filtrate turbidity ≤20NTU, it meets global environmental standards. Modular design offers 0.5-2000㎡ filtration area options, adapting to diverse production needs. Trusted by international clients, it’s your reliable partner for cost-saving and green production.
描述
Automatic Sludge Dewatering Filter Press for Leather Industry Wastewater Management
A chamber filter press is an industrial device that separates solids from liquids in a suspension by applying pressure. It’s made up of a bunch of filter plates and frames arranged alternately, with filter cloth sandwiched in between.It is widely used in wastewater treatment, chemical industry, pharmaceutical manufacturing, food and beverage production, mining, and other sectors.
A chamber filter press is a type of filter press widely used across various industries for solid-liquid separation. It is commonly employed in wastewater treatment plants, mining operations, the chemical industry, and food processing facilities.
It forces the liquid portion to pass through filter cloth while retaining solid particles within the chambers. The basic structure of a chamber filter press consists of a series of filter plates with filter cloth, alternating with solid plates. The filter plates in our products are typically made of materials such as polypropylene, cast iron, or stainless steel, depending on the application and the nature of the material being filtered. Each plate features a central cavity or chamber where solids accumulate during the filtration process.
Filtration Principle: The filter cloth acts as a medium, allowing liquid to pass through while retaining solids. This results in the formation of a filter cake within the chambers and the collection of filtrate, thereby achieving efficient solid-liquid separation.
Advantages of Chamber Filter Press
1.High Filtration Efficiency: We utilize advanced filtration technologies, such as precise filter cloth arrangement and optimized plate design, to achieve highly efficient filtration performance.
2.Robust and Durable Construction: The filter plates are typically made from high-strength polypropylene or other corrosion-resistant materials.
3.Excellent Sealing Performance: The chamber filter press is equipped with a reliable sealing system that prevents leakage and ensures consistent pressure is applied throughout the filtration process.
4.User-Friendly Operation: The equipment features automated or semi-automated control systems that simplify operation and reduce manual intervention.
5.Wide Range of Applications: Customization options are available to tailor the filter press to meet specific process requirements.
其他信息
| Structure |
Cantilever Beam Type |
|---|---|
| Filter Material |
PP or Stainless Steel |
| Pressure |
Hydraulic Pressure |
| Plate Size |
1250*1250mm |
| Cake Thickness |
30-35 |
| Plate Movement |
Automatic |
| Feeding Pressure |
0.8MPa |
| Press Pressure |
20MPa |
