B2-2008 Eccentric Shaft Outer Circle Grinding Machine

The B2-K2008 eccentric shaft CNC cylindrical grinder is a specialized machine tool designed for the grinding of small eccentric shaft parts. This machine tool has reliable accuracy and has been applied in many compressor manufacturers.
The integrated mechanical and electrical integration structure layout, overall protection, and convenient maintenance are in line with ergonomic requirements.
Special fixtures are used for headstock installation, and the workpiece is fixed by hydraulic clamping. The processing accuracy is stable.
The grinding wheel spindle adopts a sleeve-type dynamic and static pressure spindle system, featuring high rotational accuracy and strong rigidity. The grinding wheel linear speed is 45 m/s.
Two-axis feed, the worktable (Z-axis) and the grinding wheel support (X-axis) are driven by AC servo motors and ball screw pairs, with the minimum setting unit of 0.1 μm.
The diamond dressing device (installed on the rear side of the headstock) is automatic and compensates.
An active measurement device is configured to achieve full closed-loop control of the grinding process.
It uses a CNC system, featuring program transformation during the grinding process, workpiece quality management, machine status monitoring, self-diagnosis of faults, and abnormal alarm functions. It also has comprehensive control functions such as all-round control, menu-style interface input is simple and convenient.
