Customized Chamber Filter Press
$12,800.00
Our high-performance automatic box filter press is a top-tier solution for solid-liquid separation, widely applied in mining, chemical, environmental protection, food and new energy industries globally. Equipped with premium diaphragm filter plates and imported heat-treated filter cloths, it ensures a service life of over 15 years and 30-60% higher efficiency than standard models.
The 12-16Kg secondary diaphragm pressing reduces filter cake moisture content by 5-30%, while saving 20-40% energy. With PLC automatic control and remote monitoring, it enables unmanned operation and easy maintenance. Corrosion-resistant stainless steel components adapt to harsh working conditions.
描述
Customized Chamber Filter Press Plates with Overhead Beam Design for Efficient Filtration
A chamber filter press is an industrial device that separates solids from liquids in a suspension by applying pressure. It’s made up of a bunch of filter plates and frames arranged alternately, with filter cloth sandwiched in between.It is widely used in wastewater treatment, chemical industry, pharmaceutical manufacturing, food and beverage production, mining, and other sectors.
A chamber filter press is a type of filter press widely used across various industries for solid-liquid separation. It is commonly employed in wastewater treatment plants, mining operations, the chemical industry, and food processing facilities.
It forces the liquid portion to pass through filter cloth while retaining solid particles within the chambers. The basic structure of a chamber filter press consists of a series of filter plates with filter cloth, alternating with solid plates. The filter plates in our products are typically made of materials such as polypropylene, cast iron, or stainless steel, depending on the application and the nature of the material being filtered. Each plate features a central cavity or chamber where solids accumulate during the filtration process.
Filtration Principle: The filter cloth acts as a medium, allowing liquid to pass through while retaining solids. This results in the formation of a filter cake within the chambers and the collection of filtrate, thereby achieving efficient solid-liquid separation.
Key Features & Benefits:
Full Automation & Unattended Operation: Program-controlled for continuous, reliable processing with minimal manual intervention.
Efficient Cleaning System: An overhead washing device with few moving parts operates in sync with the automatic plate shifter. Cleaning cycles are customizable.
Advanced Plate Material & Design: Plates are made from a TPE elastomer, fiberglass, and polypropylene composite, delivering superior flexibility, toughness, and rigidity.
Precision Engineering: CNC-machined to a flatness of <25µm, ensuring a perfect seal (zero leakage) during pressing and feeding, which boosts filtration speed by approximately 20%.
Enhanced Durability: Offers improved cake density, structural integrity, and doubled resistance to fatigue and aging.
Superior Application Performance: Effectively replaces vacuum filters for dewatering fine-particle (<0.5mm) flotation concentrates, featuring a small footprint, high productivity, and low energy consumption.
Efficient Cleaning System: An overhead washing device with few moving parts operates in sync with the automatic plate shifter. Cleaning cycles are customizable.
Advanced Plate Material & Design: Plates are made from a TPE elastomer, fiberglass, and polypropylene composite, delivering superior flexibility, toughness, and rigidity.
Precision Engineering: CNC-machined to a flatness of <25µm, ensuring a perfect seal (zero leakage) during pressing and feeding, which boosts filtration speed by approximately 20%.
Enhanced Durability: Offers improved cake density, structural integrity, and doubled resistance to fatigue and aging.
Superior Application Performance: Effectively replaces vacuum filters for dewatering fine-particle (<0.5mm) flotation concentrates, featuring a small footprint, high productivity, and low energy consumption.
Advantages of Chamber Filter Press
1.High Filtration Efficiency: We utilize advanced filtration technologies, such as precise filter cloth arrangement and optimized plate design, to achieve highly efficient filtration performance.
2.Robust and Durable Construction: The filter plates are typically made from high-strength polypropylene or other corrosion-resistant materials.
3.Excellent Sealing Performance: The chamber filter press is equipped with a reliable sealing system that prevents leakage and ensures consistent pressure is applied throughout the filtration process.
4.User-Friendly Operation: The equipment features automated or semi-automated control systems that simplify operation and reduce manual intervention.
5.Wide Range of Applications: Customization options are available to tailor the filter press to meet specific process requirements.
2.Robust and Durable Construction: The filter plates are typically made from high-strength polypropylene or other corrosion-resistant materials.
3.Excellent Sealing Performance: The chamber filter press is equipped with a reliable sealing system that prevents leakage and ensures consistent pressure is applied throughout the filtration process.
4.User-Friendly Operation: The equipment features automated or semi-automated control systems that simplify operation and reduce manual intervention.
5.Wide Range of Applications: Customization options are available to tailor the filter press to meet specific process requirements.
其他信息
| Structure |
Cantilever Beam Type |
|---|---|
| Filter Material |
FRPP |
| Pressure |
Hydraulic Pressure |
| Filter Area |
30-1000m3 |
| Condition |
New |
| Filter Cake Thickness |
30mm |
| Filter Pressure |
0.6MPa |
