Gk Horizontal Scouring Fully Automatic Discharge Centrifuge
$50,000.00a set of
GK Horizontal Scouring Fully Automatic Discharge Centrifuge
Product Introduction
The GK type horizontal centrifuge is a fully automatic filtration centrifuge that operates continuously, intermittently, with wide scraping blades and high-speed material scraping. It can complete the processes of feeding, separation, washing, dehydration, discharging and reverse blowing at full speed. It is commonly used for the washing of suspension media containing solid-phase particles and the separation of solid and liquid phases.
The GK type horizontal centrifuge is a fully automatic filtration centrifuge that operates continuously, intermittently, with wide scraping blades and high-speed material scraping. It can complete the processes of feeding, separation, washing, dehydration, discharging and reverse blowing at full speed. It is commonly used for the washing of suspension media containing solid-phase particles and the separation of solid and liquid phases.
描述
It has a good separation effect on suspensions with a filter cake density ranging from 0.8 to 2.5, particle size within 0.05 to 1mm, and solid phase concentration within 15% to 80%. It has been widely applied in industries such as chemical engineering, food, light industry, and pharmaceuticals, for example, heavy soda ash, caustic soda, starch, boric acid, ammonium sulfate, sulfuric acid, sodium sulfate, ferrous sulfate, calcium phosphate, polyvinyl chloride, sodium chloride, potassium chloride, and similar materials.
High separation efficiency
Short cycle time
Large processing capacity
Low cake moisture content
This centrifuge is controlled by PLC program. It uses variable frequency speed regulation. The braking system adopts energy consumption braking or feedback braking. Through material level detection, speed detection, shaft temperature detection, vibration detection, etc., the entire separation process is realized with fully automatic circulation operation. The manual operation mode and the fully automatic operation mode can be freely switched.
Short cycle time
Large processing capacity
Low cake moisture content
This centrifuge is controlled by PLC program. It uses variable frequency speed regulation. The braking system adopts energy consumption braking or feedback braking. Through material level detection, speed detection, shaft temperature detection, vibration detection, etc., the entire separation process is realized with fully automatic circulation operation. The manual operation mode and the fully automatic operation mode can be freely switched.
Main features:
The coupling flange between the door cover and the machine base adopts a dovetail groove structure design, ensuring reliable sealing.
Fully hydraulic locking door cover, with dual locking protection, has a reliable structure and is easy to operate.
Fully enclosed explosion-proof structure design, meeting the GMP standards of the pharmaceutical industry and flammable and explosive environments.
Equipped with a material layer controller, effectively controlling the material thickness, preventing overloading operation and avoiding material leakage.
Hydraulic drive, stable discharge.
Detachable hard alloy blades, wear-resistant, long service life.
Spiral discharge, high filter cake collection rate, effectively preventing blockage.
Integrated with front and rear rolling bearings for support, high rigidity, low rotational resistance.
Scraping knife bracket is fully welded and smooth, with high structural strength, good rigidity, and stable scraping.
Service life can reach 30 years.
Large bearing capacity, good vibration reduction effect.
Uses anti-slip pad plates, no need for bolt fixation.
Integrated floating platform vibration reduction system structure design.
Active isolation of dynamic loads, no need for a foundation, and installation is more convenient.
The shock absorber uses imported damping, unique structural design, effectively improves the vibration isolation ability, and improves the stability and safety of equipment operation.
Integrated machine base structure design, overall full processing, safe and beautiful.
Front and rear bearing supports are processed coaxially, with high coaxial accuracy.
The main shaft sealing sleeve adopts ion plating technology, wear-resistant, corrosion-resistant, and has a long service life.
Overall welding, stress elimination, high strength, good vibration resistance.
Uses lip seal, gas seal, and labyrinth seal and other multiple sealing structures; transmission seal is reliable.
Transmission uses forced oil lubrication method, with good lubrication and cooling effect. The main shaft component is equipped with temperature measurement, speed measurement, vibration detection and other monitoring devices, which can monitor the operation of the equipment in real time.
Fully hydraulic locking door cover, with dual locking protection, has a reliable structure and is easy to operate.
Fully enclosed explosion-proof structure design, meeting the GMP standards of the pharmaceutical industry and flammable and explosive environments.
Equipped with a material layer controller, effectively controlling the material thickness, preventing overloading operation and avoiding material leakage.
Hydraulic drive, stable discharge.
Detachable hard alloy blades, wear-resistant, long service life.
Spiral discharge, high filter cake collection rate, effectively preventing blockage.
Integrated with front and rear rolling bearings for support, high rigidity, low rotational resistance.
Scraping knife bracket is fully welded and smooth, with high structural strength, good rigidity, and stable scraping.
Service life can reach 30 years.
Large bearing capacity, good vibration reduction effect.
Uses anti-slip pad plates, no need for bolt fixation.
Integrated floating platform vibration reduction system structure design.
Active isolation of dynamic loads, no need for a foundation, and installation is more convenient.
The shock absorber uses imported damping, unique structural design, effectively improves the vibration isolation ability, and improves the stability and safety of equipment operation.
Integrated machine base structure design, overall full processing, safe and beautiful.
Front and rear bearing supports are processed coaxially, with high coaxial accuracy.
The main shaft sealing sleeve adopts ion plating technology, wear-resistant, corrosion-resistant, and has a long service life.
Overall welding, stress elimination, high strength, good vibration resistance.
Uses lip seal, gas seal, and labyrinth seal and other multiple sealing structures; transmission seal is reliable.
Transmission uses forced oil lubrication method, with good lubrication and cooling effect. The main shaft component is equipped with temperature measurement, speed measurement, vibration detection and other monitoring devices, which can monitor the operation of the equipment in real time.
其他信息
| (mm)/Drum diameter |
600 |
|---|---|
| (mm)/Drum length |
325 |
| filter area |
0.61 |
| (L)/Drum volumn |
45 |
| (Kg)/Loading capacity |
60 |
| (r/min)/Drum speed |
2400 |
| Maximum separation factor |
1935 |
| (Kw)/Motor power |
22 |
| (mm)/Size |
2030x1960x1530 |
| (Kg)/Weight |
5500 |
