PSB·P Type Low-Temperature Soaking Filtration Centrifuge
$50,000.00a set of
PSB·P Type Low-Temperature Soaking Filtration Centrifuge
Product Introduction
Special centrifuge for low-temperature soaking extraction is mainly used for soaking and extracting stems of Chinese herbs and plant roots, as well as for solid-liquid separation. It is equipped with a closed filter bag, capable of separating solid particles with a diameter of ≥ 0.10mm. It is widely used in the fields of food, medicine, and chemical industry.
The low-temperature design features an immersion temperature of -40℃, which can be customized according to customer requirements. The drum volume is optional, with a large filtration area and excellent soaking and separation effects. It is equipped with quick-opening connectors, making connection more convenient.
The low-temperature design features an immersion temperature of -40℃, which can be customized according to customer requirements. The drum volume is optional, with a large filtration area and excellent soaking and separation effects. It is equipped with quick-opening connectors, making connection more convenient.
描述
Application fields
It is mainly used for soaking and extracting of Chinese herbal medicines, plant roots and stems, as well as for solid-liquid separation. It is equipped with a closed filter bag, capable of separating solid particles with a diameter of ≥ 0.10MM. It is widely applied in the fields of food, medicine and chemical industry.
It is mainly used for soaking and extracting of Chinese herbal medicines, plant roots and stems, as well as for solid-liquid separation. It is equipped with a closed filter bag, capable of separating solid particles with a diameter of ≥ 0.10MM. It is widely applied in the fields of food, medicine and chemical industry.
Solid particles are not easily broken, and the filter bags are easy to replace.
Compliant with GMP standards, with a fully enclosed structure, there are no hygiene dead corners, effectively avoiding material contamination.
Multiple safety protection configurations: pressure detection, vibration protection, opening protection, mechanical-electrical interlock, etc.
Explosion-proof design, meeting explosion-proof certification requirements.
Frequency control, energy consumption braking, enabling stepless speed variation, forward and reverse rotation.
Small floor space occupation, convenient maintenance, low failure rate, longer service life.
Compliant with GMP standards, with a fully enclosed structure, there are no hygiene dead corners, effectively avoiding material contamination.
Multiple safety protection configurations: pressure detection, vibration protection, opening protection, mechanical-electrical interlock, etc.
Explosion-proof design, meeting explosion-proof certification requirements.
Frequency control, energy consumption braking, enabling stepless speed variation, forward and reverse rotation.
Small floor space occupation, convenient maintenance, low failure rate, longer service life.
其他信息
| Effective Volume (L) |
18 |
|---|---|
| Rotary drum volume (L) |
10 |
| Diameter of the drum (mm) |
300 |
| Belt drum height (mm) |
165 |
| Shell diameter (mm) |
364 |
| Shell height (mm) |
215 |
| Maximum loading limit (kg) |
7 |
| Rotational speed of the drum (r/min) |
1970 |
| separation factor |
650 |
| Motor power (kW) |
1.5 |
| Dimensions (mm) |
950x600x1100 |
