Paut Suspended Scraper Discharge Centrifuge
$50,000.00a set of
Psd Plate-Type Discharge Centrifuge Separator with Hanging Bags
$50,000.00a set of
PSD Plate-type Discharge Centrifuge Separator with Hanging Bags
Product Introduction
The PSD type centrifuge adopts mechanical auxiliary discharge. It not only possesses the high efficiency feature of fully automatic scraper centrifuges, but also has the wide applicability advantage of the top-down discharge centrifuges. The product structure is advanced, the floor space is small, the failure rate is low, and it has a high cost-performance ratio.
描述
Main purpose
It is used for the solid-liquid separation of suspension materials with particulate solid phase, and can also be used for the solid-liquid separation of fibrous materials. For example: gypsum copper sulfate, potassium chloride, borax, dyes, pesticide agents, salt, monosodium glutamate, food additives, starch, sugar production, chemical seasonings, antibiotics, vitamins, copper, zinc, aluminum and other mineral products, metal refining, sludge treatment, sewage treatment, etc. It has been widely applied in the pharmaceutical, chemical, food, environmental protection, energy and other industries.
It is used for the solid-liquid separation of suspension materials with particulate solid phase, and can also be used for the solid-liquid separation of fibrous materials. For example: gypsum copper sulfate, potassium chloride, borax, dyes, pesticide agents, salt, monosodium glutamate, food additives, starch, sugar production, chemical seasonings, antibiotics, vitamins, copper, zinc, aluminum and other mineral products, metal refining, sludge treatment, sewage treatment, etc. It has been widely applied in the pharmaceutical, chemical, food, environmental protection, energy and other industries.
Working principle
Under the action of centrifugal force, the materials tend to move towards the inner wall of the drum. The liquid phase passes through the filter medium covering the drum wall and then through the filter holes to the inner wall of the casing and falls into the base plate, which is then discharged through the outlet. The solid-phase materials remain in the drum and can be thoroughly washed, thus completing the solid-liquid separation. After the machine stops, open the cover of the casing, use the dedicated lifting device to take out the filter bags to the discharge location for unloading. After unloading is completed, reinstall the liquid retaining plate and the filter bag into the drum and lock the liquid retaining plate, close the upturned cover, and lock it. Then, the next working cycle can start.
characteristic
Configure a hydraulic boom crane, using a dedicated lifting tool to lift and unload the materials as a whole. This method has low labor intensity and high efficiency, and the grains are less likely to be broken.
Frequency control, with adjustable separation factor. It adopts a liquid damping vibration reduction device, resulting in small vibration and stable operation.
The unique quick-disconnect liquid-blocking plate structure design makes it convenient to replace the filter cloth.
It has multiple safety protections such as nitrogen protection system, vibration protection, opening cover protection, overload protection, and mechanical interlock.
It can be configured with various options such as material layer control device, atomization washing, CIP online cleaning system, explosion-proof mirror lamp, etc.
It can be equipped with hydraulic opening cover or mechanical assistance opening cover.
Frequency control, with adjustable separation factor. It adopts a liquid damping vibration reduction device, resulting in small vibration and stable operation.
The unique quick-disconnect liquid-blocking plate structure design makes it convenient to replace the filter cloth.
It has multiple safety protections such as nitrogen protection system, vibration protection, opening cover protection, overload protection, and mechanical interlock.
It can be configured with various options such as material layer control device, atomization washing, CIP online cleaning system, explosion-proof mirror lamp, etc.
It can be equipped with hydraulic opening cover or mechanical assistance opening cover.
其他信息
| Diameter of the drum (mm) |
800 |
|---|---|
| Effective height of the drum (mm) |
450 |
| Rotary drum volume (L) |
120 |
| Maximum loading capacity (kg) |
150 |
| Motor power (kW) |
7.5 |
| Maximum rotational speed (r/min) |
1200/1500 |
| The maximum separation factor |
1007 |
| Machine weight (kg) |
1500 |
| Overall dimensions (mm) |
1730x1200x1320 |
