Reliable Automated Filter Press for Industrial Sludge Processing Needs

Name: Reliable Automated Filter Press for Industrial Sludge Processing Needs
SKU: 20553
Availability: InStock

$7,500.00

Our Plate and Frame Filter Press is a high-efficiency solid-liquid separation equipment, engineered for industrial filtration needs across mining, chemical, food, wastewater treatment and more. Adopting heavy-duty steel frame and high-quality filter plates, it features excellent pressure resistance, tight sealing and long service life. With manual/mechanical/hydraulic operation options, it ensures easy operation, stable performance and high filtration efficiency, effectively reducing moisture content of filter cake. Customizable specifications for different working conditions, reliable after-sales service and global shipping support. A cost-effective solution to optimize your production process and improve environmental compliance.

Add to compare

Add to wishlist

分类： Filter Press, Plate and Frame Filter Press

描述

Reliable Automated Filter Press for Industrial Sludge Processing Needs

A plate and frame filter press is basically a machine that separates solids from liquids. It’s made up of a bunch of filter plates and frames arranged alternately, with filter cloth sandwiched in between.It is widely used in wastewater treatment, chemical industry, pharmaceutical manufacturing, food and beverage production, mining, and other sectors.

The key components of a plate and frame filter press are the filter plates and the filter frames. These elements are arranged alternately to form a series of chambers for the slurry (a mixture of solid and liquid) to pass through. The filter plates are typically made of polypropylene or stainless steel, while the frames can be made from various materials such as plastic or metal.

A plate and frame filter press how it works: you pump the solid-liquid mixture into the spaces between the plates and frames. The liquid passes through the filter cloth and flows out, while the solids get trapped on the cloth, building up what’s called a filter cake. Once the process is done, you just take the cake out. This equipment is super common in industries like chemicals, pharmaceuticals, food processing, and wastewater treatment. The good thing is it’s really efficient at filtering, but the downside is it usually runs in batches, not continuously.”

The great thing about its design is that it’s simple and modular, so it’s easy to customize for whatever you need.

The plate and frame filter press offers several key advantages over other filtration methods, including:

1.High Filtration Efficiency: It achieves an excellent level of solid-liquid separation, producing a clear filtrate and a dry, solid cake.

2.Modular Design: Its configuration allows for easy customization to suit various processing capacities and specific application needs.

3.Low Maintenance: With a robust yet straightforward design, it requires minimal maintenance and is easy to clean.

4.Environmental Benefits: The press promotes sustainability by facilitating water reuse and significantly reducing waste.

5.Flexibility: Cake thickness can be easily adjusted by changing the frame thickness. It is suitable for a wide range of slurry characteristics.

6.Complete Cake Washing: The design allows for efficient and thorough cake washing if required.

7.Robust Construction: Simple design ensures durability and a long service life.

Key Features & Applications

Core Technology: Features stable and versatile TPE diaphragm technology for reliable performance.
Wide Applicability: Ideal for solid-liquid separation in wastewater treatment, sludge dewatering, chemical, pharmaceutical, and mining industries.
High-Pressure Operation: Utilizes water pressure (0.8-2.0 MPa) for efficient dewatering.
Enhanced Efficiency: Variable filter chamber design boosts productivity and lowers cake moisture content.
Superior Results: Achieves exceptionally low filter cake moisture, meeting landfill/incineration standards and reducing cake volume/weight.
Full Automation: Enables complete unmanned operation for reduced labor costs.

其他信息

Structure	Cantilever Beam Type
Filter Material	Cast Iron
Pressure	Hydraulic Pressure
Filter Area(M2)	100
Cubage of Filter Chamber (L)	7510
Thickness of Press Plate (mm)	30
Filter Board Specification (mm)	1500*1500
Number of Filter Plate (Piece)	125
Maximum Cylinder Stroke (mm)	750
Features	High Temperature Plate Frame Filter Press
