Versatile Automatic Filter Press

Name: Versatile Automatic Filter Press
SKU: 20494
Availability: InStock

$6,800.00

Our Plate and Frame Filter Press is a high-efficiency solid-liquid separation equipment, widely applied in mining, chemical, food, environmental protection and other industries. Adopting heavy-duty steel frame and high-quality filter plates, it features excellent pressure resistance, good sealing performance and long service life. The equipment realizes automatic filter cake discharge, saving labor costs and improving production efficiency. Customizable specifications for different working conditions, stable operation and easy maintenance. We provide one-stop after-sales service and technical support.

Add to compare

Add to wishlist

分类： Filter Press, Plate and Frame Filter Press

描述

Versatile Automatic Filter Press for Purifying Water, Wine, and Oils.

A plate and frame filter press is basically a machine that separates solids from liquids. It’s made up of a bunch of filter plates and frames arranged alternately, with filter cloth sandwiched in between.It is widely used in wastewater treatment, chemical industry, pharmaceutical manufacturing, food and beverage production, mining, and other sectors.

The key components of a plate and frame filter press are the filter plates and the filter frames. These elements are arranged alternately to form a series of chambers for the slurry (a mixture of solid and liquid) to pass through. The filter plates are typically made of polypropylene or stainless steel, while the frames can be made from various materials such as plastic or metal.

A plate and frame filter press how it works: you pump the solid-liquid mixture into the spaces between the plates and frames. The liquid passes through the filter cloth and flows out, while the solids get trapped on the cloth, building up what’s called a filter cake. Once the process is done, you just take the cake out. This equipment is super common in industries like chemicals, pharmaceuticals, food processing, and wastewater treatment. The good thing is it’s really efficient at filtering, but the downside is it usually runs in batches, not continuously.”

The great thing about its design is that it’s simple and modular, so it’s easy to customize for whatever you need.

The plate and frame filter press offers several key advantages over other filtration methods, including:

1.High Filtration Efficiency: It achieves an excellent level of solid-liquid separation, producing a clear filtrate and a dry, solid cake.

2.Modular Design: Its configuration allows for easy customization to suit various processing capacities and specific application needs.

3.Low Maintenance: With a robust yet straightforward design, it requires minimal maintenance and is easy to clean.

4.Environmental Benefits: The press promotes sustainability by facilitating water reuse and significantly reducing waste.

5.Flexibility: Cake thickness can be easily adjusted by changing the frame thickness. It is suitable for a wide range of slurry characteristics.

6.Complete Cake Washing: The design allows for efficient and thorough cake washing if required.

7.Robust Construction: Simple design ensures durability and a long service life.

Technical Features:

Fully Automatic Plate Handling – Equipped with electric or microcontroller-operated plate shifting system.
Hydraulic Drive & Pressure Control – Features a hydraulic system for plate compression and shifting, with pressure gauge-based automatic regulation for consistent operation.
Safe & User-Friendly Control – Centralized push-button panel enables continuous cycling. Includes multiple safety devices for operator protection and system reliability.
Customizable Automation – Supports optional add-ons such as cloth washing, filtrate collection, cloth vibration, and drip tray systems.

其他信息

Structure	Cantilever Beam Type
Filter Material	FRPP
Pressure	Hydraulic Pressure
Chamber Volume	3.5-20m³
Expression Pressure	0.6-2.0MPa
Cake Thickness	30mm
Filter Size	870*870mm
Motor Power	2.2kw
Plate Qty	51-147
Machinery Overseas Filter Area(M2)	30,40,50,60,70,80
Filter Chamber Volume(L)	460-1210
